Belt Bend

A belt bend module designed for e-commerce and post and parcel distribution requirements.
Ideal for transporting a wide variety of packages large and small.

Features and Benefits

  • 30°, 45°, 60° and 90° options available
  • Product weights up to 80 Kg per m
  • Easy maintenance
  • Low noise
  • Can be reversed
Features Benefits
Module Height Up to 3263mm top-of-belt
Stand Height Up to 3 metres, confirmed at time of order – discuss with Sales
Frame Construction Aluminium and mild steel construction
Paint  Finish Electrostatically applied powder coating
Drive Technology SEW hollow shaft, side mounted geared motor 230V/400V
Speeds 10 to 120 m/min
Product Weight Up to 80 Kg per metre
Belt Type Polyester with PVC top, single piece belt, pre-joined with vulcanised joint. Easily replaceable thanks to unique “pull-to-release” swivel bearings which retain the belt bead.
Environment Operating ambient 5° C to 40° C 10-50% RH non-condensing
Storage ambient -10° C to 50° C 10-50% RH non-condensing
Noise Level 49-70 dB(A) depending on speed (10-120 m/min)
